1280leds full lighting surface COB LED Strips super wide lighting surface 12mm for linear light
1280LEDS/M
DC24V
15W/M
120-140LM/W
12MM width PCB with 12mm lighting surface
- Description
- Inquiry
12mm PCB COB LED Strips 1280leds
| LED Type: | 12MM COB LED Strips |
| LED Qty: | 1280Leds/m |
| Input Voltage: | DC24V |
| Input Current: | 0.625A/m |
| Wattage:Â | 15W |
| CRI: | Ra>90 |
| CCT: | 2700K/3000K/4000K/6000K |
| LM/M @4000K/Ra80/IP20: | 110lm/m±5% |
| SDCM: | <3 |
| Cut Unit: | 12.5mm |
| IP Grade: | IP20/IP67 |
| Dimensions： | 12*5000mm |
Product Features:
Super wide lighting surface PCB Design
High Density 1280chips per meter
Zero Light Dot
Excellent Light Source for Linear Lighting
High Stability and Reliability
5 years warranty
